EX 5 — Funds bought in lots
Class: ILP · Links: integer counts, proportion constraint · Script: python/ex05_funds.py
Difficulty: ★☆☆☆☆ · Time: 30–45 min
One of the fifteen numerical models: the right place to see how a dual certificate is checked, and how a proportion constraint can defeat a greedy heuristic.
EX 5
After a win, an investor has to decide how to place \(100\) million lire. A friend suggests four types of mutual fund. Units are bought only in indivisible lots, costing \(12\), \(15\), \(18\) and \(25\) million respectively. The estimated annual return is \(1/6\) of the capital invested for the first fund, \(1/3\) for the second, \(1/9\) for the third and \(16\%\) for the fourth. Moreover the number of lots of the second fund cannot exceed \(50\%\) of the total number of lots bought. The expected annual return is to be maximised.
Model
The return of a lot is \(12 \cdot 1/6 = 2\) million for the first fund, \(15 \cdot 1/3 = 5\) for the second, \(18 \cdot 1/9 = 2\) for the third and \(25 \cdot 0.16 = 4\) for the fourth. The share constraint \(x_2 \le \tfrac12 (x_1 + x_2 + x_3 + x_4)\), multiplied by \(2\) and moved to the left, becomes \(-x_1 + x_2 - x_3 - x_4 \le 0\). With \(x_j\) the number of lots of fund \(j\):
An integer knapsack, not a binary one: the variables count lots, not choices. The first row is the budget, the second the share of the second fund written in linear form; the last declares the four variables integer and non-negative.
Constructive heuristic: the primal bound
This is a maximisation. The funds are scanned by decreasing return per million invested: \(1/3\) for the second, \(1/6\) for the first, \(4/25\) for the fourth and \(1/9\) for the third.
- Fund 2, the best one: no lot is bought. On its own it would break the share at once, which grants it at most half of the total lots.
- Fund 1: \(8\) lots are bought, \(96\) million.
- \(4\) million are left: not enough for any other lot.
The heuristic has tripped over the best fund itself. Buying a lot of it pays, but only together with a lot of another fund, and a rule that looks at one element at a time cannot see that.
LP relaxation and dual: the dual bound
With \(\alpha \ge 0\) on the budget and \(\beta \ge 0\) on the share:
With \(\alpha \ge 0\) on the budget and \(\beta \ge 0\) on the share, one row per fund.
An attempt that is not feasible
A choice that comes naturally is \(\bar\alpha = 5/32\), \(\bar\beta = 1/8\). Let us check the first constraint:
It is violated by \(1/4\): that pair is not a feasible dual solution, and the value \(100 \cdot 5/32\) is not a bound. A dual value can be read as a bound only after checking all the constraints, one by one.
The correct recipe is \(\bar\beta = 0\) and
that is, "a million is worth what it returns in the better fund". Both constraints become \(c_j\, \bar\alpha \ge p_j\) and are satisfied, and
The variable \(\alpha\) is the price of one million of budget, \(\beta\) that of the share. One row per fund: buying a lot of fund \(j\) commits \(c_j\) million and moves the share by one unit — in the direction that helps it for fund 2, in the opposite one for the others — and the total must cover the return of the lot. The objective values the whole budget at that price.
Optimum and comparison
| \(\mathit{LB}\) | \(\mathit{UB}\) | \(z(\mathit{LP})\) | \(z(\mathit{LP}^+)\) | \(z(\mathit{MILP})\) |
|---|---|---|---|---|
| 16 | \(100/3\) | \(700/27\) | \(700/27\) | 23 |
The optimum buys \(4\) lots of the first fund and \(3\) of the second, \(93\) million for a return of \(23\): the heuristic stops at \(16\) and is \(30\%\) off. The difference \(700/27 - 23 = 79/27\) is the price of integrality: the relaxation would buy lots in pieces.
Note that the dual bound built by hand, \(100/3\), stays far away: "a million is worth what it returns in the best fund" ignores that the best fund cannot be bought on its own. It is a valid recipe, not a good one.
What the share costs
Dropping the share constraint the optimum would rise from \(23\) to \(30\): six lots of the second fund and nothing else, \(90\) million spent. The share therefore costs \(7\) million of return a year, and this is how one measures what a constraint really does: remove it and see how much the optimum moves.
Code
The full script is
python/ex05_funds.py;
the notebook is
notebooks/ex05_funds.ipynb.
Show the complete script — python/ex05_funds.py (175 lines)
"""EX 5 -- Mutual funds bought in lots (family 10).
An integer (not binary) knapsack with only two lot types and a proportion
constraint rewritten in linear form. It also shows how a dual solution is checked:
an infeasible one is exhibited here first, as a
counterexample before the correct one is built.
"""
import gurobipy as gp
import pandas as pd
from gurobipy import GRB
from mip import (ammissibile, due_rilassamenti, frazione, nuovo_modello, registra_bound,
risolvi, stampa_lp, valuta)
from stile import ARANCIO, BLU, GRIGIO, TEAL, intestazione, plt, salva_dati, salva_figura
from esteso import salva_modello
R = range
# ---------- 1. MODEL AND INSTANCE ----------
intestazione("EX 5. Funds in lots: maximising the annual return within the budget")
c12 = [12, 15, 18, 25] # cost of one lot (millions)
t12 = [1 / 6, 1 / 3, 1 / 9, 0.16] # annual return, a fraction of the capital invested
nf = len(c12)
p12 = [c12[j] * t12[j] for j in R(nf)] # return of one lot: 2, 5, 2 and 4 millions
B12 = 100 # budget available
QUOTA = 0.5 # fund 2 cannot exceed half of the total lots
# in the share constraint fund 2 has coefficient +1 and the others -1
QC = [1 if j == 1 else -1 for j in R(nf)]
salva_dati(pd.DataFrame({"fund": list(R(1, nf + 1)), "lot_cost": c12, "return": t12,
"lot_return": p12}), "ex05_dati")
print(" Return of one lot: "
+ ", ".join(f"fund {j + 1} = {c12[j]} * {frazione(t12[j])} = {frazione(p12[j])}"
for j in R(nf)) + " millions.")
print(f" The constraint x2 <= {QUOTA} (x1 + x2 + x3 + x4) becomes, multiplying by 2 and "
"moving to the left, -x1 + x2 - x3 - x4 <= 0.")
def modello(c, p, B):
m = nuovo_modello("funds")
x = m.addVars(nf, vtype=GRB.INTEGER, name="x")
m.setObjective(gp.quicksum(p[j] * x[j] for j in R(nf)), GRB.MAXIMIZE)
m.addConstr(gp.quicksum(c[j] * x[j] for j in R(nf)) <= B, name="budget")
m.addConstr(gp.quicksum(QC[j] * x[j] for j in R(nf)) <= 0, name="share")
return m, x
def duale(c, p, B):
"""min B alpha s.t. c_j alpha + QC_j beta >= p_j for every fund, alpha, beta >= 0."""
d = nuovo_modello("dual_funds")
alpha = d.addVar(name="alpha") # budget
beta = d.addVar(name="beta") # share
d.setObjective(B * alpha, GRB.MINIMIZE)
d.addConstrs((c[j] * alpha + QC[j] * beta >= p[j] for j in R(nf)), name="rc")
return d
m12, x12 = modello(c12, p12, B12)
salva_modello(m12, "ex05_primale")
print(" The model of the instance:")
stampa_lp(m12)
# ---------- 2. CONSTRUCTIVE HEURISTIC (LOWER BOUND) ----------
# constructive heuristic on the return per million invested, respecting the share at every purchase
def euristica(c, p, B):
x = [0] * nf
ordine = sorted(R(nf), key=lambda j: (-p[j] / c[j], j))
passi = ["return per million invested: "
+ ", ".join(f"fund {j + 1} = {frazione(p[j])}/{c[j]} = {frazione(p[j] / c[j])}"
for j in R(nf))
+ f"; we start from fund {ordine[0] + 1}"]
for j in ordine:
comprati = 0
while True:
prova = list(x)
prova[j] += 1
if (sum(c[k] * prova[k] for k in R(nf)) > B
or sum(QC[k] * prova[k] for k in R(nf)) > 0):
break
x, comprati = prova, comprati + 1
residuo = B - sum(c[k] * x[k] for k in R(nf))
motivo = ("the remaining budget is not enough for another lot"
if residuo < c[j] else "another lot would violate the share")
passi.append(f"fund {j + 1}: {comprati} lots are bought and we stop because "
f"{motivo} ({residuo} millions left)")
return x, passi
x_eur, passi = euristica(c12, p12, B12)
for k, riga in enumerate(passi, 1):
print(f" Step {k}. {riga}")
lb12 = sum(p12[j] * x_eur[j] for j in R(nf))
sol_eur = {f"x[{j}]": x_eur[j] for j in R(nf)}
assert ammissibile(m12, sol_eur), sol_eur
print(f" Heuristic solution: {x_eur[0]} lots of fund 1 and {x_eur[1]} of fund 2 "
f"lb = {frazione(lb12)}")
# ---------- 3. LP RELAXATION AND DUAL (UPPER BOUND) ----------
d12 = duale(c12, p12, B12)
salva_modello(d12, "ex05_duale")
# counterexample: the choice alpha = 5/32, beta = 1/8 is not feasible
tentativo = {"alpha": 5 / 32, "beta": 1 / 8}
val_t, viol_t = valuta(d12, tentativo)
print(f" A NOT feasible attempt: alpha = 5/32, beta = 1/8 gives "
f"{c12[0]} * 5/32 - 1/8 = {frazione(c12[0] * 5 / 32 - 1 / 8)} < {frazione(p12[0])}: "
f"the first dual constraint is violated by {frazione(viol_t)}.")
print(" A dual value may be read as a bound only after checking ALL the constraints.")
assert viol_t > 1e-9
# correct recipe: beta = 0 and alpha equal to the highest return per million
alpha_min = max(p12[j] / c12[j] for j in R(nf))
mano = {"alpha": alpha_min, "beta": 0.0}
ub12, viol = valuta(d12, mano)
assert viol <= 1e-9, viol
print(f" Hand-built dual: beta = 0 and alpha = max_j p_j / c_j = {frazione(alpha_min)} "
"(a million is worth what it returns in the best fund),")
print(f" so every constraint c_j alpha >= p_j holds -> ub = {B12} * alpha = "
f"{frazione(ub12)}")
zlp12, zlp12r, _ = due_rilassamenti(m12, d12)
# ---------- 4. OPTIMUM OF THE MILP ----------
z12 = risolvi(m12)
print(f" Optimal solution: {int(x12[0].X)} lots of fund 1 and {int(x12[1].X)} of fund 2, "
f"spending {int(sum(c12[j] * x12[j].X for j in R(nf)))} out of {B12}, return "
f"{frazione(z12)}")
riga = registra_bound("EX 5 funds", ub12, lb12, zlp12, zlp12r, z12, senso="max")
salva_dati(pd.DataFrame([riga]), "ex05_bound")
assert lb12 <= z12 <= zlp12 <= ub12 + 1e-9
# ---------- 5. THE PRICE OF INTEGRALITY ----------
intestazione("EX 5. The price of integrality and the role of the share")
print(f" z(LP) = {frazione(zlp12)} against z(MILP) = {frazione(z12)}: the relaxation buys")
print(f" {frazione(B12 / c12[0])} lots of fund 1, which cannot be bought in pieces.")
print(f" The difference {frazione(zlp12 - z12)} is the cost of the indivisibility of the lots.")
print()
print(" The share bites: fund 2 returns more than twice the others per million invested,")
print(" and without the constraint one would buy that fund alone. With the share, every lot")
print(" of fund 2 has to be matched by a lot of some other fund:")
p_povero = [3.0 if j == 1 else p12[j] for j in R(nf)] # fund 2 down to 20 per cent
prove = []
for nome, p_alt, quota in [("original data, with share", p12, True),
("original data, without share", p12, False),
("fund 2 less profitable, with share", p_povero, True),
("fund 2 less profitable, without share", p_povero, False)]:
m, x = modello(c12, p_alt, B12)
if not quota:
m.update()
m.remove([c for c in m.getConstrs() if c.ConstrName == "share"][0])
m.update()
z = risolvi(m)
print(f" {nome:38s} z = {frazione(z):>4} "
f"x = ({', '.join(str(int(x[j].X)) for j in R(nf))})")
prove.append({"variant": nome, "z": z}
| {f"x{j + 1}": int(x[j].X) for j in R(nf)})
salva_dati(pd.DataFrame(prove), "ex05_quota")
assert prove[2]["z"] < prove[3]["z"], "with a more profitable fund 2 the share must bite"
# ---------- 6. FIGURE: THE SOLUTION ----------
# same look as the other figures of the chapter: one group of bars per fund,
# heuristic against optimum, and how much each solution commits
fig, ax = plt.subplots(figsize=(6.4, 3.0))
idx = list(R(nf))
ax.bar([j - 0.2 for j in idx], [x_eur[j] for j in idx], 0.4, color=ARANCIO,
label=f"heuristic ({frazione(lb12)})")
ax.bar([j + 0.2 for j in idx], [x12[j].X for j in idx], 0.4, color=TEAL,
label=f"optimum ({frazione(z12)})")
for j in idx:
massimo = B12 // c12[j]
ax.plot([j - 0.42, j + 0.42], [massimo, massimo], color=GRIGIO, lw=1.3, ls=":")
ax.plot([], [], color=GRIGIO, lw=1.3, ls=":", label="lots the budget alone would buy")
ax.set_xticks(idx)
ax.set_xticklabels([f"fund {j + 1}\n{c12[j]} mln a lot" for j in idx], fontsize=8)
ax.set_ylabel("lots bought")
ax.set_title(f"EX 5: the solution, {int(sum(c12[j] * x12[j].X for j in R(nf)))} millions "
f"committed out of {B12}")
salva_figura(fig, "ex05_regione")
print("Done.")
